| n° | Description | |
|---|---|---|
| 1 | Aiguille RSTDH01 |  |
| 2 | Bague 3/8” RSTDH02 |  |
| 3 | Piston RSTDH03 |  |
| 4 | Entretoise RSTDH04 |  |
| 5 | Bague bronze RSTDH05 |  |
| 6 | Joint stop jet RSTDH06 |  |
| 7 | Siège RSTDH07 |  |
| 8 | Ecrou 3/8” RSTDH08 |  |
| 9 | Corps supérieur RSTDH10 |  |
| 10 | Corps inférieur RSTDH11 |  |
| 11 | Union MM RSTDH17 |  |
| 12 | Vis inox A2 RSTDH18 |  |
| 13 | Joint de piston K17 RSTDH19 |  |
| 14 | Joint torique extérieur RSTDH20 |  |
| 15 | Joint torique intérieur RSTDH21 |  |
| 16 | Adaptateur 3/8F 1/4M RSTDH22 |  |
| 17 | Tube Tube 1 (voir p60 repère 2) |  |
| 18 | Tube 3/8” Tube 2 (voir p60 repère 3) |  |
| n° | Description | |
|---|---|---|
| 1 | Aiguille RSTDH01 | |
| 2 | Bague 3/8” RSTDH02 | |
| 3 | Piston RSTDH03 | |
| 4 | Entretoise RSTDH04 | |
| 5 | Bague bronze RSTDH05 | |
| 6 | Joint stop jet RSTDH06 | |
| 7 | Siège RSTDH07 | |
| 8 | Ecrou 3/8” RSTDH08 | |
| 9 | Manchette 3/8” RSTDH09 |  |
| 10 | Corps supérieur RSTDH10 | |
| 11 | Corps inférieur RSTDH11 | |
| 12 | Bague 1/4” RSTDH12 |  |
| 13 | Ecrou THP 1/4“ RSTDH14 |  |
| 14 | Porte buse RSTDH15 |  |
| 15 | Buse nous consulter |  |
| 16 | Union MM RSTDH17 | |
| 17 | Vis inox A2 RSTDH18 | |
| 18 | Joint de piston K17 RSTDH19 | |
| 19 | Joint torique extérieur RSTDH20 | |
| 20 | Joint torique intérieur RSTDH21 | |
| n° | Description | |
|---|---|---|
| 1 | Corps de vanne RSTDP01 |  |
| 2 | Chemise RSTDP02 |  |
| 3 | Siège RSTDP03 |  |
| 4 | Chapeau RSTDP04 |  |
| 5 | Piston RSTDP05 |  |
| 6 | Ecrou serrage buse RSTDP06 |  |
| 7 | Pastille RSTDP07 |  |
| 8 | Joint stop jet RSTDP08 |  |
| 9 | Pointeau RSTDP09 |  |
| 10 | Tête de pointeau RSTDP10 |  |
| 11 | Circlips RSTDP11 |  |
| 12 | Joint torique RSTDP12 |  |
| 13 | Joint torique RSTDP13 |  |
| 14 | Ecrou 9/16” THP RSTDP14 |  |
| 15 | Buse Nous consulter | |
| 16 | Joint torique RSTDP16 |  |
| 17 | Joint torique RSTDP17 |  |
| 18 | Piquage droit RSTDP18 |  |
| 19 | Réduction TH 3/8” 1/4” RSTDP19 |  |
